Platreef successfully completes sinking of Shaft 1 to its final depth of approximately 1,000 metres below surface

Publish date: 16 June 2020
Download PDF


Mine development work now focused on equipping Shaft 1 as Platreef’s initial production shaft

Project team achieves South African shaft-sinking industry leader status for safety performance

Updated Definitive Feasibility Study expected to be finalized in Q3 2020; will include a scoping study on the phased development production plan

MOKOPANE, SOUTH AFRICA – Ivanhoe Mines’ (TSX: IVN; OTCQX: IVPAF) Co-Chairmen Robert Friedland and Yufeng “Miles” Sun announced today that the company’s South African subsidiary, Ivanplats, has successfully completed the sinking of Shaft 1 to a final depth of 996 metres below surface, at the company’s palladium, platinum, nickel, copper, gold and rhodium Platreef mining licence.

The Platreef Project, which contains the thick, high-grade, flat-lying, underground Flatreef Deposit, is a Tier One discovery by Ivanhoe Mines’ geologists on the Northern Limb of South Africa’s Bushveld Igneous Complex; the world’s premier platinum producing region.

Underground mine development work now will focus on the construction of the 996-metre-level station at the bottom of the shaft, with final completion forecasted by the end of July 2020, well ahead of the contractual schedule. The shaft can then be reconfigured and equipped for rock, personnel and material hoisting.

The new auxiliary winder for the 7.25-metre diameter Shaft 1, which is scheduled to be delivered to Platreef later this year, will be used to assist in equipping the shaft and thereafter for logistics, shaft examination and auxiliary functions. The auxiliary winder will provide a second means of ingress and egress from the shaft after removal of the stage winder. Shaft 1 is located approximately 350 metres away from a high-grade area of the Flatreef orebody, planned for bulk-scale, mechanized mining.

“The Platreef Project has long been recognized as one of the world’s largest deposits of high-grade platinum-group metals, (PGMs) nickel and copper. With the sinking of Shaft 1 now complete, we are exploring near-term development pathways at Platreef that will allow us to expedite production at the next world-class mine on the Northern Limb,” said Mr. Friedland. “We are particularly pleased that the project remains ‘Fall-of-Ground’ incident free since shaft-sinking operations began in July 2016, which is a tribute to the excellent work by the Platreef Project team and its South African sinking contractor, Moolmans.”

The Platreef team has proudly achieved South African shaft-sinking industry leader status in terms of safety performance.

Members of the Platreef team celebrate the completion of sinking Shaft 1 to a final depth of 996 metres below surface. Shaft 1’s headframe is in the background.

Updated DFS is nearing completion, which includes a scoping study on the phased development production plan for the Platreef Project

Ivanhoe is updating the Platreef Project’s 2017 definitive feasibility study (DFS) to take into account development schedule advancement since 2017 when the DFS was completed, updated costs and refreshed metal prices and foreign exchange assumptions.

Concurrently, Ivanhoe is finalizing a Preliminary Economic Assessment (PEA) for the phased development production plan for the Platreef Project. The plan targets significantly lower initial capital, to accelerate first production by using Shaft 1 as the mine’s initial production shaft, followed by expansions to the production rate as outlined in the 2017 DFS.

The re-evaluation is being done in parallel with the ongoing mine development work to access the thick, high-grade, flat-lying Flatreef deposit that was discovered in 2010 and outlined in the Platreef 2017 Feasibility Study.

“The pending study will assess phased development options at Platreef with substantially lower upfront capital. The goal is to prioritize near-term production while safeguarding our strong balance sheet. We are confident that the project will, in time, become one of the world’s largest and lowest-cost primary producers of platinum-group metals and provide long-lasting and meaningful benefits to all of our stakeholders, including the 20 local communities − comprising approximately 150,000 local Mokopane area residents − that are our equity partners,” Mr. Friedland added.

Sifiso Mblangwe and his shaft-sinking teammates at a pre-shift safety meeting. The team achieved a South African shaft-sinking industry leader status for its safety performance.

Underground mining to incorporate highly-productive, mechanized methods

Planned mining methods will use highly-productive, mechanized methods, including long-hole stoping and drift-and-fill mining. Each method will utilize cemented backfill for maximum ore extraction. The ore will be hauled from the stopes to a series of internal ore passes and fed to the primary ore silos adjacent to Shaft 2, where it will be crushed and hoisted to surface.

Shaft 1 reached the top of the high-grade Flatreef Deposit (T1 mineralized zone) at a depth of 780.2 metres below surface in Q3 2018. The thickness of the mineralized orebody (T1 and T2 mineralized zones) at Shaft 1 is 29 metres, with grades of platinum-group metals ranging up to 11 grams per tonne (g/t) 3PE (platinum, palladium and rhodium) plus gold, as well as significant quantities of nickel and copper. The 29-metre intersection yielded approximately 3,000 tonnes of ore, estimated to contain more than 400 ounces of platinum-group metals. The ore is stockpiled on surface and is being used for metallurgical test work.

Platreef’s shaft-sinking team operating the six-boom jumbo to drill the final round to a depth of 996 metres below surface. Underground development work now will focus on the construction of the 996-metre-level station.

The development of the three primary mining access level stations has been completed with only the 996 metre spillage clearing level remaining, which will be completed by end July 2020. The three development stations will provide initial, underground access to the high-grade orebody. Shaft 1 changeover detailed designs are being completed and will enable Shaft 1 to be configured for permanent hoisting and dewatering.

The mining zones in the current Platreef Mine plan occur at depths ranging from approximately 700 metres to 1,200 metres below surface. When completed, Shaft 2 is expected to provide primary access to the mining zones; secondary access is expected to be via Shaft 1. During mine production, both shafts also are expected to serve as ventilation intakes. Three additional ventilation exhaust raises are planned to achieve steady-state production.

Ivanplats received its Integrated Water Use Licence in January 2019, which is valid for 30 years and enables the Platreef Project to make use of water as planned in the 2017 DFS.

Figure 1: Schematic section of the Platreef Mine, showing Flatreef’s T1 and T2 thick, high-grade mineralized zones (red and dark orange), underground development work completed to date in shafts 1 and 2 (white) and planned development work (gray).

Revenue per tonne of ore at the Platreef Project in South African Rand near all-time highs

Significant increases in the price of palladium, rhodium, gold and nickel over the last three years has resulted in the weighted price of the ‘basket’ of metals contained in the ore at the Platreef palladium-platinum-rhodium-nickel-copper-gold project to rise to levels that are significantly higher than when the 2017 DFS was completed. In addition, the South African Rand has depreciated significantly against the US dollar in recent years, resulting in the weighted price of Platreef’s ‘basket’ of metals in South African Rand trading near all-time highs.

Figure 2. Revenue per tonne of ore at the Platreef Project since 2016 (shown in US dollars)

Figure 3. Revenue per tonne of ore at the Platreef Project has risen steadily since 2016 (shown in South African rand).

Source for figures 1 & 2: Bloomberg. Based on historical weekly commodity prices at the end of each week.

Notes for Figures 1 and 2:

  1. Based on Platreef Mineral Reserves with an effective date of May 24, 2017.
  2. Probable Mineral Reserve of 124.7 million tonnes at a grade of 1.95 grams per tonne (g/t) platinum, 2.01 g/t palladium, 0.30 g/t gold, 0.14 g/t rhodium, 0.34% nickel and 0.17% copper.
  3. A declining NSR cut-off of $155 per tonne (t) to $80/t was used for the Mineral Reserve estimates.
  4. The NSR cut-off is an elevated cut-off above the marginal economic cut-off.
  5. Metal prices used in the Mineral Reserve estimate: US$1,600 per ounce (oz) platinum, US$815/oz palladium, US$1,300/oz gold, US$1,500/oz rhodium, US$8.90 per pound (lb) nickel and US$3.00/lb copper.
  6. Tonnage and grade estimates include dilution and mining recovery allowances.
  7. Applies life-of-mine average recoveries of 87.4% for platinum, 86.9% for palladium, 78.6% for gold, 80.5% for rhodium, 87.9% for copper and 71.9% for nickel.
  8. Total cash cost includes mine site costs, plus realization costs such as treatment and refining charges, royalties and transportation.
