500-ktpa smelter to be the largest copper smelter in Africa, and one of the world’s largest single-line smelters
Metso Outotec’s state-of-the-art, environmentally-friendly smelter technology aligned with Kamoa-Kakula’s goal of producing the world’s ‘greenest copper’
KOLWEZI, DEMOCRATIC REPUBLIC OF CONGO & NANCHANG, CHINA – Ivanhoe Mines (TSX: IVN; OTCQX: IVPAF) Co-Chairs Robert Friedland and Yufeng “Miles” Sun are pleased to announce that Kamoa Copper has awarded China Nerin Engineering Co., Ltd. (Nerin) of Jiangxi, China, with the basic engineering contract for the planned, direct-to-blister flash smelter at the Kamoa-Kakula Copper Complex that will incorporate leading-edge technology supplied by Metso Outotec of Espoo, Finland, and have a nameplate capacity of 500,000 tonnes a year of approximately 99%-pure blister copper.
The contract was signed earlier today by Mark Farren, CEO of Kamoa Copper, and Wu Runhua, General Manager of Nerin, at a virtual ceremony held at the Kamoa-Kakula Mine and Nanchang City.Jinghe Chen, Chairman of Zijin Mining; Zhang Xiaobo, Chairman of Nerin; along with Mr. Friedland and Mr. Sun, joined the signing ceremony to offer their congratulations and support for this important project milestone.
The planned Kamoa-Kakula smelter is to be built adjacent to the Phase 1 and Phase 2 concentrator plants, and is designed to use technology supplied by Metso Outotec and to meet the International Finance Corporation’s (IFC) emissions standards. The smelter has been sized to process the majority of the copper concentrate forecast to be produced by Kamoa-Kakula’s Phase 1, Phase 2 and Phase 3 concentrators. With a nameplate capacity of 500,000 tonnes per annum of blister copper, it is projected to be one of the largest, single-line blister-copper flash smelters in the world, and the largest in Africa.
Kamoa Copper’s executive team members at the virtual signing ceremony. (L-R, seated): Ben Munanga, Chairman; Mark Farren, CEO; and Rochelle De Villiers, Co-CFO. (L-R standing) Zhilin Li, Deputy General Manager; Annebel Oosthuizen, Executive, Finance; Xuelin Cai (Minty), Co-CFO; and Yong Chen, COO.
Nerin is an international engineering company with more than 60 years of experience in smelter engineering and construction projects globally. Nerin actively promotes the advancement of smelting technology through its own research and development, and establishing various partnerships with global industry peers, including Metso Outotec.
Since its inception in 1957, Nerin has undertaken more than 4,000 engineering and construction projects in 60 countries, including numerous large-scale, flash smelting projects, which comprise approximately 47% of the world’s current flash-smelting capacity. Notable projects include the upgrading of Rio Tinto’s Kennecott smelter inSalt Lake City, Utah, United States, and the upgrading and expansion of Glencore’s PASAR smelter and refinery in Isabel, Leyte Philippines. Nerin’s exceptional capabilities in flash-smelting technology, combined with its significant experience in the DRC (including the Lualaba Copper Smelter near Kolwezi that is treating approximately one-third of Kamoa-Kakula’s current concentrate output, and Tenke Fungurume’s copper hydrometallurgical plant) will help ensure a smooth execution of the planned smelter at Kamoa-Kakula.
The smelter is expected to be built concurrently with the project’s Phase 3 mine and concentrator expansion, and the upgrading of turbine 5 at the Inga II hydropower complex. The additional 162 megawatts of renewable electricity from the Inga II upgrading project will be needed to power the Phase 3 expansion and on-site smelter.
The next stages in the smelter project development will be the completion of basic engineering, which is expected to take approximately seven months, and the ordering of the long-lead equipment, followed by earthworks which are expected to commence in Q2 2022. The awarding of the Engineering, Procurement and Construction Management (EPCM) contract is expected to occur shortly after the commencement of the earthworks.
The overall execution timeline will be dictated by the basic engineering, but is expected to be approximately three years. The expected capital cost is in the region of US$700 million (100%-basis) for the enlarged smelter, to be financed with cash flows from Kamoa-Kakula.
An onsite smelting facility has compelling cost and environmental benefits, including a reduction in the volume of copper concentrate shipped from the mine by approximately one half or more, and the associated logistics costs, export taxes and concentrate treatment charges. The smelter also will produce sulphuric acid as a by-product, creating a new revenue stream for Kamoa Copper.
There is a strong demand and market for sulphuric acid in the DRC to recover copper from oxide ores. Copper mines in the DRC currently import significant volumes of sulphur used in sulphur-burning acid plants to produce sulphuric acid for the treatment of oxide copper ores. The DRC also imports sulphuric acid, primarily from Zambia.
Kamoa-Kakula currently is producing an extremely high-grade, clean copper concentrate containing approximately 55% copper and extremely low levels of arsenic by world standards – approximately 0.01%. Approximately 35% of Kamoa-Kakula’s Phase 1 concentrate is sent to the local Lualaba smelter for processing into blister copper ingots – containing approximately 99% copper – while the remainder is transported via trucks and ships to international smelters for treatment.
Mark Farren commented: “Today’s signing of the smelter basic engineering contract with Nerin highlights our commitment to the people of the DRC toderive more economic benefits from Kamoa-Kakula by maximizing in-country beneficiation. Achieving the transformative potential of Kamoa-Kakula’s unrivaled copper resources requires creative thinking that supports the DRC’s priorities of economic growth and diversification through value-addition, processing and beneficiation.
“Nerin is a highly-respected engineering firm with the people and in-country expertise to deliver a first-rate, on-site smelter that will be among the largest of its kind in the world. They successfully built the local Lualaba Copper Smelter, to which we are sending about a third of our current concentrate output.
“After a great deal of due diligence, the partners at Kamoa Copper collectively agree that the state-of-the-art, environmentally-friendly technology offered by the Metso Outotec direct-to-blister smelter best suits the unique low-iron, low-sulphur and ultra-high-grade concentrate produced at Kamoa-Kakula, and aligns seamlessly with our goal of producing the world’s ‘greenest copper’.
“The Kamoa-Kakula smelter will be powered by clean, renewable hydropower and will incorporate leading-edge sulphur capture. Shipping 99%-pure blister copper ingots produced from an on-site smelter, instead of shipping copper concentrate, will result in a significant reduction in Kamoa-Kakula’s concentrate transportation costs and Scope 3 emissions.”
Wu Runhua, General Manager of Nerin (seated, centre) and Xiaobo Zhang, Chairman of Nerin (standing behind Wu Runhua), and other members of China Nerin Engineering join members of Ivanhoe Mines’ Chinese representative office at the signing ceremony in Nanchang City, China, with the Kamoa Copper team on the screen in the background.
Aerial view of the Kamoa-Kakula Copper Complex. The planned smelter is to be built within the area outlined in red, adjacent to the Phase 1 and 2 concentrator plants (in yellow circle). The backfill plant is circled in blue.
Benefits of the Metso Outotec direct-to-blister smelting technology
Approximately one-half of the world’s primary copper currently is produced using flash, direct-to-blister smelting technology. Metso Outotec recently signed a major engineering and technology contract for the delivery of a landmark copper smelter complex to be built in Gresik, East Java, Indonesia. The project owner is PT Freeport Indonesia and has a value of EUR 360 million (US$424 million).
The Outotec technology produces high-quality blister copper in a single flash furnace without the need for separate converting stages or ladle transportation. The process and equipment have undergone continuous development over the last 70 years, which has led to one of the safest, most environmentally-friendly, and most reliable smelting processes for treating high-grade copper concentrates.
Summary of direct-to-blister smelting key features:
- Often the most profitable process option for concentrates containing more than 30% copper.
- Results in high copper recovery.
- Requires no converting process.
- Low capital and maintenance costs.
- Integrated controls with continuous process.
- High sulphur recovery due to single, continuous, stable gas stream, leading to minimum emissions to the environment.
- Low capital and operational costs for sulphuric acid plant.
A Metso Outotec direct-to-blister flash smelter furnace in operation.
Kakula is projected to be the world’s highest-grade major copper mine, with an initial mining rate of 3.8 million tonnes per annum (Mtpa) at an estimated, average feed grade of more than 6.0% copper over the first five years of operations, and 5.9% copper over the initial 10 years of operations. Phase 1 is expected to produce approximately 200,000 tonnes of copper per year, while the Phase 2 expansion is forecast to increase production to approximately 400,000 tonnes of copper annually. Kamoa Copper is on track to complete the Phase 2 expansion in Q2 2022.
Based on independent benchmarking, the project’s phased expansion scenario to 19 Mtpa would position Kamoa-Kakula as the world’s second-largest copper mining complex, with peak annual copper production of more than 800,000 tonnes.
The Kamoa-Kakula Copper Project is a joint venture between Ivanhoe Mines (39.6%), Zijin Mining Group (39.6%), Crystal River Global Limited (0.8%) and the Government of the Democratic Republic of Congo (20%). A 2020 independent audit of Kamoa-Kakula’s greenhouse gas intensity metrics performed by Hatch Ltd. of Mississauga, Canada, confirmed that the project will be among the world’s lowest greenhouse gas emitters per unit of copper produced.
Disclosures of a scientific or technical nature regarding development scenarios at the Kamoa-Kakula Project in this news release have been reviewed and approved by Steve Amos, who is considered, by virtue of his education, experience and professional association, a Qualified Person under the terms of NI 43-101. Mr. Amos is not considered independent under NI 43-101 as he is Kamoa Copper’s Head of Projects. Mr. Amos has verified the technical data disclosed in this news release.
Ivanhoe has prepared an independent, NI 43-101-compliant technical report for the Kamoa-Kakula Project, which is available on the company’s website and under the company’s SEDAR profile at www.sedar.com:
- Kamoa-Kakula Integrated Development Plan 2020 dated October 13, 2020, prepared by OreWin Pty Ltd., China Nerin Engineering Co., Ltd., DRA Global, Epoch Resources, Golder Associates Africa, KGHM Cuprum R&D Centre Ltd., Outotec Oyj, Paterson and Cooke, Stantec Consulting International LLC, SRK Consulting Inc., and Wood plc.
The technical report includes relevant information regarding the assumptions, parameters and methods of the mineral resource estimates on the Kamoa-Kakula Project cited in this news release, as well as information regarding data verification, exploration procedures and other matters relevant to the scientific and technical disclosure contained in this news release.
About Ivanhoe Mines
Ivanhoe Mines is a Canadian mining company focused on advancing its three principal projects in Southern Africa: the development of major new, mechanized, underground mines at the Kamoa-Kakula copper discoveries in the Democratic Republic of Congo and at the Platreef palladium-rhodium-platinum-nickel-copper-gold discovery in South Africa; and the extensive redevelopment and upgrading of the historic Kipushi zinc-copper-germanium-silver mine, also in the Democratic Republic of Congo.
Kamoa-Kakula began producing copper concentrates in May 2021 and, through phased expansions, is positioned to become one of the world’s largest copper producers. Kamoa-Kakula is being powered by clean, renewable hydro-generated electricity and is projected to be among the world’s lowest greenhouse gas emitters per unit of metal produced. Ivanhoe Mines has pledged to achieve net-zero operational greenhouse gas emissions (Scope 1 and 2) at the Kamoa-Kakula Copper Mine. Ivanhoe also is exploring for new copper discoveries on its Western Foreland exploration licences in the Democratic Republic of Congo, near the Kamoa-Kakula Project.
Investors: Bill Trenaman +1.604.331.9834 / Media: Matthew Keevil +1.604.558.1034
Kamoa Copper: Ben Munanga +243.972.995.117
